Sytong AM03-35LRF Thermal Imaging Scope

DESCRIPTION

SYTONG AM03-35LRF THERMAL RIFLE SCOPE WITH RANGE FINDER AND BALLISTICS

The Sytong AM03-35LRF features a high resolution 384×288, 12µm, sub 30 NETD sensor and is available in either a 35mm / F1.0 aperture with a wide field of view or 50mm /F1.0 with a higher base magnification for longer range.

Like all other Sytong products, long run time is provided from a convenient, easily obtained, single 18650 battery.

SPECIFICATIONS:

• SENSOR

Type: Uncooled

Frame Rate: 50 Hz

NETD: <30mk

Resolution: 384×288

Pixel Size: 12µm

• OPTICAL CHARACTERISTICS

Objective Lens:35mm / F1.0

Digital Zoom: 1x / 2x / 4x / 8x

Dioptre Adjustment: +5 / -5D

Magnification: 2.8x

Eye Relief: 50mm

Focus Range: 5m – ∞

Detection Range (Human Size): 1750m

F.O.V: 7.5°x5.7°

• DISPLAY

Type / Resolution: 0.39″ / OLED / 1024×768

Operating Mode: White Hot, Sky Mode, Black Hot, Red Hot, Fusion

• RANGEFINDER

Max. Measuring Range: 800m

Measuring Accuracy: ± 1m

Wavelength:905nm

• OPERATIONAL CHARACTERISTICS

3D Gyroscope: Yes

Battery: 18650 / 3500mAh

Waterproof Rating: IP66

Operating Temperature: -20°C – +50°C

Operating Time at 22°C: 6 Hours

Power Supply: 3-4.2V

External Power Supply: 5V (USB)

Dimensions: 209mm x 62mm x 87mm

Weight (Without Battery): 605g

Max Recoil Handling: 10,000 J

• VIDEO RECORDER

Video / Photo Resolution: 1024×768

Supported Memory Type: Built-in 32G Memory Card

Video / Photo Format: .mp4 / .jpg

WIFI CHANNEL

Frequency: 2.4GHz

Line of Sight Reception Range: 15m
